"Safely Filter and Reuse System Fluids Over and Over Again With Perfect Filtration's Portable Filters!"

These portable units conveniently remove water and ultra-fine contamination anywhere you need to clean or reclaim:
  • Transmission and Hydraulic Oils

  • Lubricating and Gear Oils

  • Hydrocarbons and Synthetic Fluids

  • Transformer Oil

  • Glycol and Water Based Coolants

  • Drawing, Cutting and Quenching Oils

  • Ester Based Fluids and More!

Saving you a fortune in fluid costs!

 Contact us About Perfect Filtration Portable Filters!

Don't Throw It Away - Filter and Reuse It!

Perfect Filtration's Portable Fluid Filters easily move from job to job and feature the same incredible filtration technology as the stationary filters.

With 10 different element materials and 4 different flow depths, the Ultimate Portable Filters can achieve the desired cleanliness level (less than 1 micron) for nearly any fluid, thick or thin!

Perfect Filtration when and where you need it!


The "Ultimate" Portable Filtration System Features:

  • Heavy Duty Construction

  • Pressure Gauge to Monitor Element Condition

  • Element Lifter for Easy Removal of Saturated Filters

  • Quiet, Easy to Service Rotary Gear Positive Displacement Pump

  • Inlet Strainer to Protect Pump

  • 115 Volt 1 Phase or 220 Volt 3 Phase Available

  • Hi/Lo Pressure Switch for Unattended Operation

  • Fluid Transfer With or Without Filtering

Operation Modes:

  • Filter Only (re-circulate fluid in reservoir)

  • Filter and Transfer

  • Transfer Only

How effective is it? Take a look at these tests
measured by electronic counter!

HOW CLEAN IS CLEAN? Note that these tests were performed on NEW OIL! If these filters can clean up NEW oil this well, just imagine what they can do for your dirty used fluids!

Oil Tested Total Particles 5-10 micron 11-25 micron 26-50 micron 51-100 micron 100+ micron
New Oil 147,388 128,080 13,436 4,543 1,111 218
After Filtering 60 59 0 1 0 0
New Oil 42,233 36,468 2,807 709 227 2,022
After Filtering 30 28 1 1 0 0


Contact us about Perfect Filtration Portable Filters!

OR
See what people are saying about Perfect Filtration!


Portable Filter Applications and Dimensions

Perfect filtration has single, and dual housing units available to cover a wide variety of filtration needs. Whether it's coolant, mineral spirits, hydraulic oil, lubricating oil, or one of many other fluids, it can be kept clean (or reclaimed) and used many times longer with the "Ultimate" 1 micron portable filter!

Contact us for Perfect Filtration Portable Filter
Pricing, Dimensions and Application Details

or Click here to see the entire Perfect Filtration line
